Antennas and RF Accessories
This section describes antennas, RF Accessories, and their configuration for the access point.
Cisco recommends using a coax seal (such as CoaxSeal) for outdoor connections, to prevent moisture and other weathering elements
from affecting performance. For more information on using coax seal on the N connector to cable or antenna interface, see the
instructions on your antenna documents.
Antenna Types and Models
The antennas used in these configurations are:
• Cisco Aironet Dual-Band Omnidirectional Antenna (White model—Cisco PID AIR-ANT2547V-N)
Cisco Aironet Dual-Band Omnidirectional Antenna (Cisco PID AIR-ANT2547VG-N)
These are the related models:
◦
White model (Cisco PID AIR-ANT2547V-N=)
◦
Grey Model (Cisco PID AIR-ANT2547VG-N=)
•
Cisco Aironet Four-Port Dual-Band Polarization-Diverse Array Antenna (Cisco PID AIR-ANT2513P4M-N)
•
Cisco Aironet Four-Element, MIMO, Dual-Band Ceiling Mount Omnidirectional Antenna (Cisco PID AIR-ANT2524V4C-R)
•
Cisco Aironet Dual-Band MIMO Wall-Mounted Omnidirectional Antenna (Cisco PID AIR-ANT2544V4M-R)
• Cisco Aironet 2.4 GHz/5 GHz MIMO 4-Element Patch Antenna (Cisco PID AIR-ANT2566P4W-R)
•
Cisco Aironet Dual-band Dipole Antenna (Cisco PID AIR-ANT2524DB-R, AIR-ANT2524DG-R, and AIR-ANT2524DW-R)
•
Cisco Aironet 2.4-GHz 13-dBi Directional Antenna (Cisco PID AIR-ANT2413P2M-N)
•
Cisco Aironet 5-GHz 14-dBi Directional Antenna (Cisco PID AIR-ANT5114P2M-N)
• Cisco Aironet 2.4 GHz/5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R)
RF Accessories
This section contains the IW3702 RF accessories: cables, adapters, and lightning arrestors.
The following table defines the cables available for interconnecting the antennas and the access point.
Table 4: RF Cables
Loss at 5.8 GHzLoss at 2.4 GHzDescription
2
Cisco PID
N(m) to N(m) RF cables:
0.8 dB0.5 dBN(m)-R/A to N(m)-STR,
LMR-240 , 2ft RF cable
Type: Indoor Interconnect.
Not DB, CMR or CMP
AIR-CAB002L240-N
25
