Cisco MDS 9148 User Manual

11
Send documentation comments to mdsfeedback-doc@cisco.com
Figure 13 Device Manager Login
Step 4 Click FC, and then choose VSANs.
Step 5 Click Create.
Step 6 Use the Create VSAN General dialog box to create a VSAN, as shown in Figure 14.
Figure 14 VSAN Creation
Step 7 Click Finish to save your changes.
Step 8 Repeat Step 6 and 7 to create more VSANs.
Note For more information on how to create VSANs, see the Cisco MDS 9000 Family CLI Configuration Guide.
This completes the installation of your Cisco MDS 9148. The switch is now ready to use.

Cisco MDS 9148 Specifications

General

Form Factor	1RU
Switching Capacity	768 Gbps
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-40 to 158°F (-40 to 70°C)
Port Speed	4/8/16 Gbps
Throughput	384 Gbps
Latency	Less than 2 microseconds
Power Supply	Dual hot-swappable
Management	CLI
Fibre Channel Zoning	Hardware enforced zoning
Relative Humidity	5 to 95% non-condensing
Dimensions	1.72 x 17.3 x 19.5 inches
