Cisco ME 1200 Series - Rack Mounting Variations; Wall Mounting

2-7
Cisco ME 1200 Series Carrier Ethernet Access Devices Hardware Installation Guide
OL-31962-04
Chapter 2 Installing the Cisco ME 1200 NID
Installation the Switch
Mounting the Switch using 19-inch, 23-inch, and ETSI Brackets
Figure 2-3 Mounting the Switch
•
For Cable manager, use part number ME1200-CAB-MNGT
Mounting the Switch on a Wall
Note The wall mounting screws are user-supplied.
1
Phillips flat-head screws
2
Cable guide and screw
