Cisco Meraki Catalyst 9300/X/L-M Series - Product View and Physical Features; Front Panel Components

C9300L-48P-4X
48 x 1GbE RJ45
4 x 1G/10G SFP+
Uplink
PoE+/802.3bt 67.40 / 598 W 505W Yes, Dual
C9300L-48PF-4X
48 x 1GbE RJ45
4 x 1G/10G SFP+
Uplink
PoE+/802.3bt
67.38 /
1023.56 W
890W Yes, Dual
C9300L-24UXG-4X
8 x 100M/1G/2.5G/5G/
10G mGig
16 x 1G (1G/100M/
10M) GbE RJ45
4 x 1G/10G SFP+
Uplink
UPoE/802.3bt
68.98 /
1049.47 W
880W Yes, Dual
C9300L-48UXG-4X
12 x 100M/1G/2.5G/
5G/10G mGig
36 x 1G (1G/100M/
10M) GbE RJ45
4 x 1G/10G SFP+
Uplink
UPoE/802.3bt
104.56 / 875.3
W
675W Yes, Dual
Product View and Physical Features
Front Panel Components
Inactive components: When operating in the Meraki-managed mode, the C9300 will disable the STAT, Duplex, Speed,
Stack, PoE, XPS and Console LEDs, as well as the USB Type-A storage and the USB Type-B console ports.
Item Component Purpose
5
