Table 10: System Controller LED Descriptions
StatusColorLED
The operator has activated this LED to identify this module in the chassis.Flashing blueATTN
This module is not being identified.Off
This module is operational.
GreenSTS
The host kernel has booted and is ready to start System Administrator VM.Amber
Either of the following conditions:
• The module has detected a slot ID parity error and will not power on or
boot up.
• The module is not fully inserted.
Red
The module is not receiving power.Off
The module is booting up or shutting down.Flashing
Amber
The module has active major or critical alarms.Flashing Red
The controller module is operational and in active mode. This mode is
established after the SysAdmin VM is booted up.
GreenACT
The controller module is operational and in standby mode.Amber
The hardware mastership has not been established.Off
Hardware Installation Guide for Cisco NCS 5500 Series Modular Routers
131
