Cisco NCS 5508

Management port link and
active LEDs
4
Table 11: Route Processor Card LED Descriptions
StatusColorLED
The operator has activated this LED to identify this module in the
chassis.
Flashing blueATTN (Attention)
This module is not being identified.Off
This module is operational.
GreenSTS (Status)
The module is booting up or shutting down.Flashing
amber
The module has active major or critical alarms.Flashing red
Host kernel booted and is ready to start System Administrator VM.Amber
Either of the following conditions:
• The module has detected a slot ID parity error and will not power
on or boot up.
• The module is not fully inserted.
Red
The module is not receiving power.Off
XR VM is operational and is in the active redundancy role on this
module.
GreenACT (Active)
XR VM is operational and is in the standby redundancy role on this
module.
Amber
XR VM is not operational on this module.Off
The management port is linked up.
GreenManagement port
LINK
The management port is not linked up.Off
The management port is transmitting or receiving.
Flashing greenManagement port
ACT
The management port is not transmitting or receiving.Off
The 1588 port is linked up.
Green1588 port LINK
(NC55-RP-E only)
The 1588 port is not linked up.Off
The 1588 port is transmitting or receiving.
Flashing green1588 port ACT
(NC55-RP-E only)
The 1588 port is not transmitting or receiving.Off
Hardware Installation Guide for Cisco NCS 5500 Series Modular Routers
133
