Cisco NCS 5508

Screws2Side brackets1
b) Use 4 M6 screws with (4.5 N-m) 40 in-lbs of torque to attach the side bracket to the chassis.
c) Repeat a and b on the other side of the chassis.
d) Slide the rack mount bracket through the side bracket.
Hardware Installation Guide for Cisco NCS 5500 Series Modular Routers
39
Install the Chassis
(Only NCS 5504) Install the Rear Chassis Brackets
