Cisco NCS 5508

The cable management brackets (optional), also referred to as side filter frames can be ordered separately. To
install the cable management brackets follow the steps (Step 1 and Step 2) in this procedure, “(Optional)
Install Air Filter, Cable Management Bracket, or Door Kit on a Chassis ”. The PIDs for the cable management
brackets are:
• NCS-5504-CAB-MGMT=
• NCS-5508-CAB-MGMT=
• NCS-5516-CAB-MGMT=
Note
Step 1 Attach the two side extension brackets to the chassis as follows:
a) Remove the screws from the bottom support rails. Save the screws for re-installation.
b) Position one of the side extension brackets on the vertical mounting bracket and the bottom support rails so that the
two screw holes are aligned.
c) Secure the extension bracket to the chassis vertical mounting bracket with M6 x 19 mm (or 12-24 X ¾ inch screws),
pan-head, Phillips screws. Note that these are the screws you removed earlier in Step a. Tighten each screw to 40
in-lb (4.5 N·m) of torque. The number of screws can vary based on the chassis.
d) Repeat Steps 1a - 1c to attach the other side of the extension bracket to the vertical mounting bracket on the opposite
side of the chassis.
