The following table describes the global LLDP attributes that the user can configure:
Table 3:
DescriptionRangeDefaultAttribute
Specifies the hold time (in
sec). Hold time refers to
the time or duration that
an LLDP device maintains
the neighbor information
before discarding.
0–65535120Holdtime
Delay (in sec) for LLDP
initialization on any
interface
2–52Reinit
Specifies the rate at which
LLDP packets are sent (in
sec)
5-6553430Timer
The following example shows the commands to configure LLDP globally. The global LLDP configuration
enables LLDP on all the three management interfaces.
RP/0/RP0/CPU0:regen#configure terminal
RP/0/RP0/CPU0:regen(config)#lldp management enable
RP/0/RP0/CPU0:regen(config)#lldp holdtime 30
RP/0/RP0/CPU0:regen(config)#lldp reinit 2
RP/0/RP0/CPU0:regen(config)#commit
Verification
You can verify the LLDP configuration using the show running-config lldp command.
The output of show running-config lldp command is as follows:
RP/0/RP0/CPU0:regen#show running-config lldp
Tue Dec 10 10:36:11.567 UTC
lldp
timer 30
reinit 2
holdtime 120
management enable
!
You can verify the LLDP data using the show lldp interface and show lldp neighbors commands.
The output of show lldp interface command is as follows:
RP/0/RP0/CPU0:regen#show lldp interface
Thu Nov 7 08:45:22.934 UTC
MgmtEth0/RP0/CPU0/0:
Tx: enabled
Rx: enabled
Tx state: IDLE
Rx state: WAIT FOR FRAME
MgmtEth0/RP0/CPU0/1:
