Ethernet Compliance Code: 100GBASE-LR4
Transceiver Temperature : 27 Celsius
AINS Soak : Pending
AINS Timer : 0h, 2m
AINS remaining time : 120 seconds
To override the default AINS settings on a specific controller, use the following commands:
automatic-in-service controller optics R/S/I/P hours hours minutes minutes
This configuration does not persist after a RP reload operation.
Note
The following is a sample in which the optics controller on the OTN-XP card is configured with a soak time
period of 45 minutes.
RP/0/RP0/CPU0:ios#automatic-in-service controller optics 0/1/0/0 hours 0 minutes 45
Tue Apr 28 11:55:15.666 UTC
RP/0/RP0/CPU0:ios#show controllers optics 0/1/0/0
Tue Apr 28 11:55:30.323 UTC
Controller State: Down
Transport Admin State: Automatic In Service
Laser State: On
LED State: Red
Optics Status
Optics Type: 100G QSFP28 LR4
Alarm Status:
-------------
Detected Alarms: None
LOS/LOL/Fault Status:
Alarm Statistics:
-------------
HIGH-RX-PWR = 0 LOW-RX-PWR = 0
HIGH-TX-PWR = 0 LOW-TX-PWR = 0
HIGH-LBC = 0 HIGH-DGD = 0
OOR-CD = 0 OSNR = 0
WVL-OOL = 0 MEA = 0
IMPROPER-REM = 0
TX-POWER-PROV-MISMATCH = 0
Performance Monitoring: Enable
THRESHOLD VALUES
----------------
Parameter High Alarm Low Alarm High Warning Low Warning
Configuring Controllers
9
Configuring Controllers
Configuring AINS on OTN-XP Card
