10
Installing and Upgrading Internal Modules in Cisco 2800 Series Routers
OL-5792-04
Locating Modules
Figure 9 Module Locations in Cisco 2811 Routers
1 AIM connectors 5 Primary power connector
2 DRAM DIMMs 6 Secondary power connector
3 PVDMs 7 Fans
4 Power supply
1
1
4
6
5
2
3
103394
7
