Installing and Upgrading Internal Modules in Cisco 2800 Series Routers
OL-5792-04
Locating Modules
Figure 10 Module Locations in Cisco 2821 Router
1 AIM connectors 4 Power supply connectors
2 DRAM DIMMs 5 Fans
3 PVDMs
4
1
1
2
3
5
103393
