1-45
Cisco ONS 15454 DWDM Procedure Guide, R8.0
78-17704-02
Chapter 1 Install the Shelf and Common Control Cards
NTP- G8 Install the Fan-Tray Assembly
Figure 1-20 Installing the Fan-Tray Assembly on the ONS 15454 ANSI
Step 3
To verify that the tray has plugged into the assembly, look at the fan tray and listen to determine that the
fans are running.
Step 4 If you want to install an alarm expansion panel on the ONS 15454 ANSI shelf, continue with the
“NTP-G9 Install the Alarm Expansion Panel (ANSI Only)” procedure on page 1-46. Otherwise, continue
with the “NTP-G10 Attach Wires to Alarm, Timing, LAN, and Craft Pin Connections” procedure on
page 1-49.
Stop. You have completed this procedure.
277184
Fan tray
assembly
LCD
