D14908.02 SX20 Administrator Guide TC6.0, JANUARY 2013. www.cisco.com — Copyright © 2012-2013 Cisco Systems, Inc. All rights reserved.
8
Cisco TelePresence SX20 Quick Set Administrator Guide
System configuration changes
New settings
Audio Input HDMI Mode
Conference DoNotDisturb DefaultTimeout
Conference MaxTotalTransmitCallRate
Conference MaxTotalReceiveCallRate
Conference Presentation RelayQuality
Conference Presentation OnPlacedOnHold
Network QoS Diffserv ICMPv6
Network QoS Diffserv NTP
NetworkServices CTMS Mode
NetworkServices CTMS Encryption
NetworkServices XMLAPI Mode
SIP ListenPort
Video SelfviewDefault Mode
Video SelfviewDefault FullscreenMode
Video SelfviewDefault PIPPosition
Video SelfviewDefault OnMonitorRole
Video PIP ActiveSpeaker DefaultValue Position
Video PIP Presentation DefaultValue Position
Video Input Source[1..n] PresentationSelection
Video Input HDMI[1..n] RGBQuantizationRange
Video Input DVI[x, y] RGBQuantizationRange
Video Output HDMI[x, y] RGBQuantizationRange
Video OSD MenuStartupMode
Video OSD VirtualKeyboard
Video OSD EncryptionIndicator
Video OSD MissedCallsNotification
Settings that are removed
Network DNS Server[4, 5] Address
Settings that are modified
Cameras PowerLine Frequency
OLD: <Auto/50Hz/60Hz>
NEW: <50Hz/60Hz>
Conference DefaultCall Protocol
OLD: <H323/Sip>
NEW: <H323/Sip/H320>
Network IPv6 Assignment
OLD: <Static/Autoconf>
NEW: <Static/DHCPv6/Autoconf>
SystemUnit ContactInfo Type
OLD: <Auto/None/IPv4/IPv6/H323Id/E164Alias/SipUri/
SystemName>
NEW: <Auto/None/IPv4/IPv6/H323Id/E164Alias/
H320Number/SipUri/SystemName/DisplayName>
UserInterface TouchPanel DefaultPanel
OLD: <ContactList/MeetingList>
NEW: <ContactList/MeetingList/Dialpad>
Video SelfviewPosition
OLD: <UpperLeft/UpperRight/CenterRight/LowerLeft/
LowerRight>
NEW: <UpperLeft/UpperCenter/UpperRight/CenterLeft/
CenterRight/LowerLeft/LowerRight>
Video Layout LocalLayoutFamily
OLD: <Auto/FullScreen/Equal/PresentationSmallSpeaker/
PresentationLargeSpeaker>
NEW: <Auto/FullScreen/Equal/PresentationSmallSpeaker/
PresentationLargeSpeaker/Prominent/Overlay/Single>
Video Layout RemoteLayoutFamily
OLD: <Auto/FullScreen/Equal/PresentationSmallSpeaker/
PresentationLargeSpeaker>
NEW: <Auto/FullScreen/Equal/PresentationSmallSpeaker/
PresentationLargeSpeaker/Prominent/Overlay/Single>
Video Input Source[1..n] OptimalDefinition Threshold60fps
OLD: <512_288/768_448/1024_576/1280_720/Never>
NEW: <512_288/768_448/1024_576/1280_720/
1920_1080/Never>
Video Wallpaper
OLD: <None/Growing/Summersky/Custom/Wallpaper01/
Wallpaper02/Wallpaper03/Wallpaper04/Wallpaper05/
Wallpaper06/Wallpaper07/Wallpaper08/Wallpaper09/
Wallpaper10/Wallpaper11/Wallpaper12>
NEW: <None/Growing/Summersky/Custom/Waves>
Contents
Introduction
Web interface
System settings
Setting passwords
Appendices
Introduction
