Cisco TelePresence MX700 and MX800 Administrator Guide
Video compositor GPIO
Advanced customization of video
The video system supports full customization of the video
layouts/templates allowing support for advanced meeting
room setups and integrations.
The TC Console application, which is a free software tool
that runs on PC/Mac, provides a graphical interface to the
advanced customizable features of the codec. TC Console
includes the following modules:
Video compositor
• Modify the default video compositing behavior of the
codec
• Add new layouts
• Change the automatically chosen layout
• Control what video sources are shown where and when
GPIO
• Change the behavior of the GPIO, i.e. what the codec
should do when pins go high/low
For more details about the functionality, see the
user guide included in the TC Console application
itself or download the TC Console user guide from
► http://www.cisco.com/go/mx-docs
How to obtain the TC Console application
Download the TC Console application for free from
the Cisco Developer Network (CDN) web site. Go to:
► http://developer.cisco.com/web/telepresence-developer
Contents
Introduction
Web interface
System settings
Setting passwords
AppendicesAppendices

Cisco TelePresence MX200 G2 Specifications

General

Resolution	1920 x 1080
Network	10/100/1000 Ethernet
Product Type	Video conferencing system
Display Size	42 in
Camera	PrecisionHD 1080p Camera
Codec	Cisco TelePresence Codec
Video Inputs	HDMI, DVI-I
Video Outputs	HDMI
Control	Cisco Touch 10
Video Standards	H.264
Connectivity	HDMI
Codec Support	H.264
Resolution (fps)	1080p30
