Chapter 1 Overview
Disk
Management
Factory-configured RAID
9
support options, which differ for the LFF and SFF
versions of the server.
• LFF:
– RAID 0 and 1 support for up to 4 SATA drives with the integrated SATA
controller.
Note The integrated ICH10R RAID controller is not compatible for use with
VMWare ESX/ESXi Server software in any generation or version of the
Cisco UCS C200 server.
– RAID 0, 1, and 1E support for up to 4 SAS or SATA drives with the optional
LSI 1064-based controller mezzanine card.
– RAID 0, 1, 5, 6, 00, 10, 50 and 60 support for up to 4 SAS or SATA drives
with the optional LSI 9260-8i MegaRAID controller card.
• SFF:
– RAID 0 and 1 support for up to 4 SATA drives with the integrated SATA
controller.
Note The integrated ICH10R RAID controller is not compatible for use with
VMWare ESX/ESXi Server software in any generation or version of the
Cisco UCS C200 server.
– RAID 0, 1, and 1E support for up to 4 SAS or SATA drives with the optional
LSI 1068-based controller mezzanine card.
– RAID 0, 1, 5, 6, 00, 10, 50 and 60 support for up to 8 SAS or SATA drives
with the optional LSI 9260-8i MegaRAID controller card.
– RAID 0, 1, 5, 6, 00, 10, 50 and 60 support for up to 4 SAS or SATA drives
with the optional LSI 9280-4i4e MegaRAID controller card.
See RAID Controller Considerations, page C-1 for more information about RAID in
this server.
Video The server CIMC chip includes a Matrox G200 core. The Matrox G200 core shares
the same memory as the rest of the CIMC. The first 8 MB of memory are allocated
to the video core, followed by another 5 MB allocated to the compression engine for
difference buffers.
1. DIMM = dual inline memory module
2. DDR = double data rate (transfer mode)
3. SAS = serial attached SCSI
4. SATA = serial advanced technology attachment
5. VGA = video graphics array
6. USB = universal serial bus
7. KVM = keyboard, video, mouse
8. PCIe = peripheral component interconnect express
Table 1-1 Hardware Features of the Server (continued)
Feature or
Component Cisco UCS C200 Server

Cisco UCS C200 Specifications
