Cisco UCS C200 Server Installation and Service Guide
OL-20732-02
Chapter 1 Overview
The Cisco UCS C200 server has the following components and features. Differences between the Large
Form Factor (LFF) version of the server (PID R200-1120402W) and the Small Form Factor (SFF)
version of the server (PID UCS-BSE-SFF-C200) are noted.
.
Ta b l e 1-1 Hardware Features of the Server
Feature or
Component
Cisco UCS C200 Server
Enclosure Single rack unit (1RU) chassis.
Processors Up to two quad-core Intel Xeon processors.
Memory 12 DIMM
1
slots supporting up to 96 GB of industry-standard DDR3
2
main memory.
Storage The number of drives depends on which configurable front panel you have:
• LFF—Up to 4 internal 3.5-inch SAS
3
or SATA
4
drives.
• SFF—Up to 8 internal 2.5-inch SAS or SATA drives.
Server Generation M2 only—There is also one internal USB port on the
motherboard that you can use with a USB thumb drive (see
Figure 3-7).
Network and
management I/O
The server provides these rear-panel connectors:
• Two 10/100/1000 Gigabit Ethernet ports (RJ-45 connectors).
These integrated Gigabit ports support the Wake on LAN (WoL) and TCP/IP
Offload Engine (TOE) standards.
• One 10/100 Ethernet port (RJ-45 connector).
• One DB9 serial connector.
• One DB15 VGA
5
connector.
• Two USB
6
2.0 connectors.
The server also has one front-panel console connector (with supplied KVM
7
cable,
provides DB15 video, DB9 serial, and two USB 2.0 connectors).
Note The Cisco UCS C200 SFF server does not include a front-panel KVM
connector if ordered with the optional DVD module.
Removable media
devices
One internal DVD drive:
• LFF—The DVD drive is not field-replaceable.
• SFF—The optional front panel DVD module is field-replaceable.
The drive supports the following media types: CD-R, CD-ROM, CD-RW, DVD+R,
DVD+RW, DVD-R, DVD-ROM, DVD-RW, +R DL
Power Up to two power supplies, each with a maximum output of 650W (redundant power
supply is optional).
Cooling Five internal fans that force front-to-rear cooling; also one fan in each power supply.
PCIe I/O Up to two PCIe
8
expansion cards, plugged into horizontal riser card sockets:
• One standard-profile, half-length, x16-lane, x16 connector (on riser card).
• One low-profile, half-length, x8-lane, x8 connector (on riser card).
