Cisco UCS C210 M2 Spec Sheet

Cisco UCS C210 M2 General-Purpose Rack-Mount Server
18
CONFIGURING the SERVER
.
R2XX-PL003 LSI MegaRAID SAS 9261-8i (RAID 0, 1, 5, 6, 10)
■ Takes up one of five available PCIe slots (must be installed in slot #4)
■ Supports up to eight internal SAS or SATA drives with the factory default SAS
Extender installed. You can mix SAS and SATA drive types, but you cannot mix
HDD and SSD drive types.
■ Supports up to 16 internal SAS or SATA drives with the optional SAS Expander
installed. You can mix SAS and SATA drive types, but you cannot mix HDD and
SSD drive types.
■ Includes 512 MB of write cache
■ Battery backup option available (see the battery backup PID section in this
table)
■ Factory-configured RAID options: RAID 0, 1, 5, 6, 10 (see the RAID PIDs
section in this table)
RAID Battery Backup Option (not available with mezzanine card)
R2XX-LBBU2 Battery Backup
RAID Configuration (note: Mezzanine card supports only RAID 0, 1, and 1E)
R2XX-RAID0 Factory pre-configured RAID striping option
Enable RAID 0 Setting. Requires a minimum of 1 hard drive.
R2XX-RAID1 Factory pre-configured RAID mirroring option
Enable RAID 1 Setting. Requires exactly 2 drives, with same size, speed, capacity.
R2XX-RAID5 Factory pre-configured RAID option
Enable RAID 5 Setting. Requires minimum 3 drives of same size, speed, capacity.
R2XX-RAID6 Factory pre-configured RAID option
Enable RAID 6 Setting. Requires minimum 4 drives of same size, speed, capacity.
R2XX-RAID10 Factory pre-configured RAID option
Enable RAID 10 Setting. Requires an even number of drives (minimum 4 drives) of
same size, speed, capacity.
NOTE: No RAID option can be chosen if you have one of the following configurations:
• A mix of SAS and SATA drives
•No drives
Table 6 Available RAID Options (continued)
Product ID (PID) PID Description
