3-70

Cisco UCS C240 M4 Server Installation and Service Guide

OL-32474-01

Chapter 3 Maintaining the Server

Installing or Replacing Server Components

Figure 3-33 mLOM Card Location

1 mLOM card socket location on motherboard

(under PCIe riser 1)

352967

FAN 05FAN 06

FAN 04

FAN 0 3

FAN 02

FAN 01

CPU 1

CPU 2

SD1

SD2

Riser 2

Riser 1

1
