Cisco UCS C240 M4

A-4
Cisco UCS C240 M4 Server Installation and Service Guide
OL-32474-01
Appendix A Server Specifications
Power Specifications
1400 W AC Power Supply
Table A-2 lists the specifications for each 1400 W AC power supply
(Cisco part number UCSC-PSU2-1400=).
Table A-4 1400 W Power Supply Specifications
Description Specification
AC input voltage Nominal range: 200–240 VAC
(Range: 180–264 VAC)
AC input frequency Nominal range: 50 to 60Hz
(Range: 47–63 Hz)
Maximum AC input current 8.5 A at 200 VAC
Maximum input volt-amperes 1700 VA
Maximum output power per PSU 1400 W at 200–240 VAC
Maximum inrush current 35 A (sub-cycle duration)
Maximum hold-up time 12 ms at 1200 W
Power supply output voltage 12 VDC
Power supply standby voltage 12 VDC
Efficiency rating Climate Savers Platinum Efficiency (80Plus Platinum
certified)
Form factor RSP1
Input connector IEC320 C14
