Chapter 1 Overview
Storage Drives are installed into front-panel drive bays that provide hot-swappable access
for SAS/SATA drives. The server is orderable in four different versions, each with
one of four different front panel/backplane configurations:
• Cisco UCS C240 M4—Small form-factor (SFF) drives with 24-drive
backplane and expander. This version holds up to 24 2.5-inch SAS/SATA hard
drives or solid state drives (SSDs). This version also supports up to 2 NVMe
PCIe SSDs.
• Cisco UCS C240 M4—SFF drives with 16-drive backplane and integrated
expander. This version holds up to 16 2.5-inch SAS/SATA hard drives or solid
state drives. This version also supports up to 2 NVMe PCIe SSDs.
• Cisco UCS C240 M4—SFF drives with 8-drive direct-connect backplane and
no expander. This version holds up to 8 2.5-inch SAS/SATA hard drives or
solid state drives. This version also supports up to 2 NVMe PCIe SSDs.
• Cisco UCS C240 M4—Large form-factor (LFF) drives with 12-drive
backplane and integrated expander. This version holds up to 12 3.5-inch
SAS/SATA hard drives.
Note You cannot change the backplane type after-factory. To change a front
panel/backplane configuration, a chassis replacement is required.
Internal USB One internal USB 3.0 port on the motherboard that you can use with a USB thumb
drive for additional storage.
SD cards Two internal bays on the motherboard for up to two SD cards.
The two flash drives can be configured in a RAID 1 configuration.
Disk
Management
(RAID)
Dedicated internal socket for a PCIe-style RAID controller card.
The server can optionally use its own embedded SATA RAID controller with the
installation of a SATA interposer board. You can optionally add a RAID 5 key to
upgrade this SATA RAID.
For a list of RAID
5
controller options and required cabling, see RAID Controller
Considerations, page C-1.
RAID Backup Mounting point on the air baffle for the supercap power module that is used with
the Cisco modular RAID controller card.
Video VGA video resolution up to 1920 x 1200, 16 bpp at 60 Hz, and up to 256 MB of
video memory.
1. DIMM = dual inline memory module
2. VGA = video graphics array
3. USB = universal serial bus
4. PCIe = peripheral component interconnect express
5. RAID = redundant array of independent disks
Table 1-1 Cisco UCS C240 M4 Server Features (continued)

Cisco UCS C240 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
Processor model	E5-2650V3
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Embedded options available	No
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60
Total storage capacity	- GB
Maximum storage capacity	- TB
Number of HDDs installed	-
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
LAN controller	Intel® I350
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux Oracle Solaris Ubuntu Server CentOS
Chassis type	Rack (2U)
Power supply input frequency	50 - 60 Hz
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Trusted Platform Module (TPM) version	1.2
PCI Express slots version	3.0

Weight and Dimensions

Depth	738 mm
Width	448 mm
Height	87 mm
