3-24

Cisco UCS C240 M4 Server Installation and Service Guide

OL-32474-01

Chapter 3 Maintaining the Server

Installing or Replacing Server Components

Figure 3-14 Fan Modules Latch and Fault LED

1 Finger latch (on each fan module) 2 Fan module fault LED (on each fan module)

352959

FAN 05

FAN 04

FAN 0 3

FAN 02

FAN 01

CPU 1

CPU 2

SD1

SD2

Riser 2

Riser 1

1 2
