Chapter 3 Maintaining the Server
Installing or Replacing Server Components
Figure 3-21 SCPM (RAID Backup Unit) Mounting Point and Cable Path
1 SCPM mounting point on removable air baffle
(air baffle not shown)
2 SCPM cable routing path (the red line)
352962
FAN 05
FAN 04
FAN 0 3
FAN 02
FAN 01
CPU 1
CPU 2
SD1 SD2
Riser 2
Riser 1
1
2
