2-11
Cisco UCS S3260 Storage Server Chassis Installation and Service Guide
Chapter 2 Installing the System
Installing the System in a Rack
Figure 2-5 Attaching the Cable Management Arm to the Rear of the Slide Rails
1 CMA tab on arm farthest from system and end
of stationary outer slide rail
3 CMA tab on width-adjustment slider and end
of stationary outer slide rail
2 CMA tab on arm closest to the system and end
of inner slide rail attached to system
4 Rear of system
352584
1
4
2
3
