DescriptionColor
This appears on the switch in a StackPower ring configuration that detects an open
ring or has only one StackPower cable connected.
Blinking green
There is a fault: load shedding is occurring, a StackPower cable is defective, or an
administrative action is required. See the switch software configuration guide for
information about configuring StackPower.
Amber
The StackPower budget is not sufficient to meet current power demands.Blinking amber
ACTV LED
Table 9: ACTV LED
DescriptionColor
Switch is not the active switch.Off
Switch is the active switch or a standalone switch.Green
Switch is in stack standby mode.Slow blinking green
An error occurred when the switch was selecting the active switch, or another type
of stack error occurred.
Amber
STACK LED
The STACK LED shows the sequence of member switches in a stack. Up to nine switches can be members
of a stack. The first nine port LEDs show the member number of a switch in a stack.
Figure 9: STACK LED
This figure shows the LEDs on for each switch. When you press the Mode button to select the STACK LED,
the corresponding port LEDs will blink green for each switch. For example, for switch 1, port 1 will blink
green and the rest of the LEDs will be off. On switch 2, port 2 will blink green and the rest of the LEDs will
be off. The same behavior will be seen with the remaining switches in the
stack.
Catalyst 3850 Switch Hardware Installation Guide
OL-26779-0520
Product Overview
ACTV LED
