Table 17:
SpecificationItem
MIMO, dipole swivelAntenna type
10 WattsInput power
SMA maleConnector
50 OhmsNominal
impedance
OmnidirectionalRadiation pattern
698MHz to 960MHz and 1710MHz to 2700MhzFrequency range
F (–40°C to 85°C)Temperature range
Length: 6.37 in. (16.19 cm)
Width: 0.9 in. (2.38 cm)
Depth: 0.63 in. (1.59 cm)
Antenna
dimensions
Noncondensing, 65°C, 95% RHHumidity
Front and Rear Panel Components
This article describes the components on the front and rear panels of the vEdge 100m router. See At a Glance
for the exact location of these components on the router.
Front Panel LEDs
The vEdge 100m router has five chassis status LEDs located on the front panel. Table 1 describes the LEDs
, their color and states, and the status they indicate.
Table 18:
StatusColorLED
• Off: System is not on
• Green: System is healthy and operational
• Red: Power supply fault
Green/RedPower
Hardware Installation Guide for vEdge Routers
57
vEdge 100m Router
Front and Rear Panel Components
