Cisco Systems, Inc.

Page 13 of 29

• Cisco 7600 Series 1-Port OC-48c/STM-16 PoS/SDH/OSM:

http://www.cisco.com/en/US/products/hw/routers/ps368/products_data_sheet09186a0080092241.html

• Cisco 7600 Series 2- and 4-Port OC-12c/STM-4 PoS/SDH OSM:

http://www.cisco.com/en/US/products/hw/routers/ps368/products_data_sheet09186a008009223e.html

• Cisco 7600 Series 2-Port ATM OSM:

http://www.cisco.com/en/US/products/hw/routers/ps368/products_data_sheet09186a008008876f.html

• Cisco 7600 Series 2-Port OC-48c/1-Port OC-48c DPT OSM:

http://www.cisco.com/en/US/products/hw/routers/ps368/products_data_sheet09186a0080088774.html

Layer 4 Through 7 Services Modules

The Cisco Catalyst 6500 Series offers an extensive set of services modules for Layer 4 through 7 applications,

including content services, network monitoring, security, and telephony.

Content Services Modules

• ContentServices Gateway (CSG)—Enables differentiated billing, user balanceenforcement, andactivity tracking

for customer billing systems. For more information, visit: http://mobiletraining.cisco.com/csg/CSGe_ds_0211.pdf

• Content Switching Module (CSM)—Integrates advanced content switching into the Cisco Catalyst 6500 Series

to provide high-performance, high-availability load balancing of caches, ﬁrewalls, Web servers, and other

network devices. For more information, visit:

http://www.cisco.com/en/US/products/hw/modules/ps2706/products_data_sheet09186a00800887f3.html

Network Monitoring

• Network Analysis Module (NAM 1 and 2)—Provides application-level visibility into the network infrastructure

for real-time trafﬁc analysis, performance monitoring, and troubleshooting; performs trafﬁc monitoring with

embedded Web-based trafﬁc analyzer. For more information, visit:

http://www.cisco.com/en/US/products/hw/modules/ps2706/products_data_sheet09186a00800a2c89.html

Security Services Modules

• Firewall Services Module (FWSM)—The FWSM allows any port in the chassis to operate as a ﬁrewall port

and integrates stateful ﬁrewall security inside the network infrastructure. For more information, visit:

http://www.cisco.com/en/US/products/hw/modules/ps2706/products_data_sheet09 186a00800c4fe7.html

• IntrusionDetection System Module(IDSM and IDSM-2)—Takestrafﬁc from theswitch backplane atwire speed,

integrating IDS functions directly into the switch. For more information, visit:

http://www.cisco.com/en/US/products/hw/modules/ps2706/products_data_sheet09186a0080092341.html

• IPSec VPN Module (IVSM)—Provides infrastructure-integrated IPSec VPN services capable of 1.9-Gbps Triple

Data Encryption Standard (3DES) performance, 8000 active tunnels, and up to 60 tunnels per second. For more

information, visit:

http://www.cisco.com/en/US/products/hw/modules/ps2706/products_data_sheet09 186a00800c4fe2.html

• SSL Services Module (SSM)—Ofﬂoads processor-intensive tasks related to securing trafﬁc with SSL accelerating

the performance and increasing the security of Web-enabled applications. For more information, visit:

http://www.cisco.com/en/US/products/hw/modules/ps2706/products_data_sheet09186a00800c4fe9.html

Questions and Answers:

Need help?

Do you have a question about the Cisco WS-C6509 and is the answer not in the manual?

Cisco WS-C6509 Specifications

General

Model	WS-C6509
Backplane Capacity	720 Gbps
Forwarding Rate	400 Mpps
Layer Support	Layer 3
Redundancy	Yes (Supervisor, Power Supply)
Product Type	Switch
Ports	Dependent on installed modules
RAM	Dependent on Supervisor Engine
Flash Memory	Dependent on Supervisor Engine
Product Series	Catalyst 6500
Operating System	Cisco IOS
Management	CLI, SNMP, Web
MAC Address Table Size	128, 000
Jumbo Frame Support	9216 bytes
Supervisor Engine	Multiple options (e.g., Supervisor Engine 720, Supervisor Engine 32)
