Fan Trays
Chassis that have a Supervisor Engine 720 installed require a high-speed fan tray. See Table 5 for part number
information.
Table 4 Power Supply VAC and VDC Requirements
Power Supply AC Input Voltage/Current DC Input Voltage/Current
950W 100 to 240 VAC ( 10% for full range); 15 A –48 VDC to –60 VDC continuous; 38 A @
–48 VDC, 30 A @ –60 VDC
1000W 100 to 240 VAC ( 10% for full range); 12 A @ 100 VAC,
6 A @ 240 VAC
Not supported
1300W 100 to 240 VAC ( 10% for full range); 17.25 A @
100 VAC, 8 A @ 200 VAC
–48 VDC to –60 VDC continuous; 38 A @
–48 VDC, 30 A @ –60 VDC
1400W 100 to 240 VAC ( 10% for full range); 15 A Not supported
2500W 100 to 120 VAC, 200 to 240 VAC ( 10% for full range);
16 A maximum at 200 VAC at 2500 W output; 16 A
maximum at 100 VAC at 1300 W output
–48 VDC to –60 VDC continuous; 80 A @
–40.5 VDC, 70 A @ –48 VDC, 55 A @
–60 VDC
3000W 100 to 120 VAC, 200 to 240 VAC ( 10% for full range);
16 A maximum at 200 VAC at 3000 W output; 16 A
maximum at 100 VAC at 1450 W output
Not Supported
4000W 100 to 240 VAC ( 10% for full range); 23 A –48 VDC to –60 VDC continuous; 80 A @
–40.5 VDC, 70 A @ –48 VDC, 55 A @
–60 VDC
Table 5 Catalyst 6500 Chassis Fan Tray Part Numbers
Catalyst 6500
Chassis
Normal Speed Fan—Fan Tray Part Number High Speed Fan—Fan Tray Part Number
6503 FAN-MOD-3 FAN-MOD-3-HS(=)
6506 WS-C6K-6SLOT-FAN WS-C6K-6SLOT-FAN2
6509 WS-C6K-6SLOT-FAN WS-C6K-9SLOT-FAN2
6509-NEB WS-C6509-NEB-FAN WS-C6509-NEB-FAN2
6509-NEB-A N/A FAN-MOD-09(=)
6513 WS-C6K-13SLOT-FAN WS-C6K-13SLOT-FAN2
