Practical information
Berlingo-2-VP_en_Chap04_Ergonomie_ed02-2015
MODUTOP ROOF BARS
Themaximumauthorisedweighton
eachroofbaris35kg.
Inallcases,theloadmustreston
the non-slip bands provided for this
purposeandmustnottouchtheroofor
theglazingoftheroof.
Recommendations for loading the
roof
This procedure requires the use of
a spanner supplied with the tools for
changingawheel.
These two longitudinal Modutop roof
barscanberemoved.
Chapter9,"Changingawheel"
section.
- Opentheprotectivecovers.
- Slackenthefourscrewsusingthe
spannerandremovethem.
- Turnthebars90°placingthe
hollowpartstowardsthefront.
- Retthethe4screwsandtighten
themusingthespanner.
- Closetheprotectivecovers.
- Use the strap passages A only to
securetheloadrmly.
