CLUTCH
GEARBOX
DRIVESHAFTS
AL4 GEARBOX CONTROLS
Engine : KFV
Close to the gearbox.
Control of the automatic gearbox is by a cable.
«c» Push button.
(1) Control lever with ball-joint.
(2) Automatic adjustment.
Pull out the button to permit adjustment of the control.
Press in the button to lock the adjustment of the control.
(3) Sleeve stop.
(4) Selection control locking clip (5), on the sleeve stop (3).
B2CP3H8C
