173
CLUTCH
GEARBOX
DRIVESHAFTS
AL4 GEARBOX CONTROLS
Engine : KFV
Unlocking: «Shift lock» function.
NOTE : The «shift lock» is a system that locks the gear selection lever in position «P».
Unlocking the «shift lock». (Normal operation).
Switch on the ignition.
Press the brake pedal and keep it pressed.
Move the gear selection lever out of position «P».
Unlocking the «shift lock». (With an operating fault).
NOTE : It is impossible to unlock the «shift lock» with the «Normal operation» method.
The fault may originate from one of the following components:
- «Shift lock».
- Gear lever position switch.
- Automatic gearbox ECU.
- Electrical harness.
- Battery voltage.
Remove:
- The gear lever knob (1) (Pull upwards).
- The cover (2) (Unclip).
- The top of the central console (3).
- Unlock the «shift lock» (4) with the aid of a screwdriver.
- Move the gear selection lever out of position «P».
B2CP3GZCC5FP0ETC
