OPERATION No MA. 00-855
: Fitting the side finishing strips.
Op. MA. 00-855 3
1. Fitting the upper door finishing strips (1 ) :
/
Mark the following :
I
- on the front door, the point u a 1 1) at a distance of 23 mm from the front upper corner of the door and 10 mm from
I
. the window surround embellishers,
- on the rear door, the point (( a 7 )) 31 mm from the front edge of the door, and 10 mm from the window surround
embellisher,
- on the rear wing the point u a 13 1) 35 mm from the front edge of the wing, and 6 mm from the upper edge of the
wing.
Using a piece of string, draw a line passing through each point, and draw the axis of the strips.
Mark the axis of the strip fixing holes (see diagram page 2 ), as well as the holes at (( a 17 )) and CC a 18 )).
Drill the holes ( 5 mm diameter ).
Fit the plastic clips.
Position the strips on the clips.
2 2. Fitting the rubbing roils (2) ot the centre of the doors :
0
2
Mark the front and rear points at a distance of 260 mm at the front and 208 mm at the rear from the waistline of
2
the vehicle.
2
Mark the central axis of the rubbing rail using a length of string.
2
Draw a line linking the holes as per diagram on page 2.
Drill all the holes (diameter = 8 mm).
s
5
Fit the plastic clips, and secure them.
a
Position and fit the rubbing rails onto the clips.
a
2
