<Output Signal List (EtherCAT Specifications) (1/2)>
AX (Output)  PLC
Index
Sub
Index
Display Name bit Description Logic
0x3000
0x01 Input signal 1
0 M code output (bit 0) Positive
1 M code output (bit 1) Positive
2 M code output (bit 2) Positive
3 M code output (bit 3) Positive
4 M code output (bit 4) Positive
5 M code output (bit 5) Positive
6 M code output (bit 6) Positive
7 M code output (bit 7) Positive
8 In-position output Positive
9 Positioning completion output Positive
10 Start input wait output Positive
11 Alarm output 1 Negative
12 Alarm output 2 Negative
13
Output 1 during indexing /
Home position output
Positive
14
Output 2 during indexing /
Servo state output
Positive
15 Ready output Positive
16 Segment position strobe output Positive
17 M code strobe output Positive
18
to
31
Unavailable
0x02 Input signal 2
0 Monitoring Positive
1 Instruction code execution completion Positive
2 to
31
Unavailable
0x3001
0x01 Input data 1 - Monitor data 1
0x02 Input data 2 - Monitor data 2
0x03 Input data 3 - Monitor data 3
0x04 Input data 4 - Monitor data 4
0x05 Input data 5 - Monitor data 5
