４．６．１ Actualmeasurementcalibration
Displaysthenewlyconvertedreferencevaluebasedonthemastersettingandopensettingpressure.
Settingorder[1]→[2]
Note)Thethresholdmustbereconfiguredafterconductingactualmeasurementcalibration.
[1]Mastersetting:
Afterinstallingthereferencemastergauge,enterthereferencevaluenumerically
andrecordthepressurewiththemastergaugeinstalled.
[2]Opensetting:
Recordthepressurewiththenozzleopen.
Note)Fullyopenthenozzlewhenusingthissetting.
４．６．２ Settingofdisplaycolor （Factorydefault:Goo）
SetstheCH1/2ON/OFFdisplaycolors.
４．６．３ Settingofscreennon-display （Factorydefault:OFF）
Setsthemain/subscreennon-displaysettings.
Non-displayforallexceptoutputdisplayandnotificationdisplay.
(WiththissettingONand3minuteswithoutkeyoperation)
green
Setting
contents
Displaycolor
Nooutput CH1：ON CH2：ON
Goo green orange orange
oGG orange green
