５．１ Periodicinspection
(1)Dailyinspection
・Beforeoperatingtheproduct,confirmproperoperation.
・Beforeusingthisproduct,itisoperatingcorrectly,pleaseperformtheoperationconfirmation.
(2）Periodicinspection
・Tooperatetheproductinitsoptimaloperatingstate,carryouttheperiodicinspection
normallyonceeverysixmonths.
・Checkthatnoleakoccursinthepiping.
５．２ Disassemblyandreassembly
a）Beforedisassemblingorcleaningtheorifice,turnthepowerOFF,stopthesupply
ofcompressedairandmakesurethatthereisnoresidualpressure.
b）Donotdisassemblytheproductasitwillaffectperformance.
Readinstructionsandprecautionsenclosedwiththeproductbeforestartinguse
ordisassembly.
５．２．１ Orificecleaning
Itispossibletocleanforeignmatteraccumulatedintheinternalorifice.
■Disassemblyprocedure
1)Pleaseremovethepinfromtheproductbodywithathintoolsuchasaflatheadscrewdriver.
2)Pullthecartridgefittingandpullitoutfromtheproductbody.
Pin
Cartridgefitting
CAUTION
WARNING
