■Cleaningprocedure
1)RemovetheO-ringfromthecartridgefitting.
2)Pleasecleantheorificesectionofthecartridgefitting.
Note)Wipeofftheinternalorificewithairbloworasoftcloth.
Iftheorificeisscratched,itwillnotbeabletodetectnormally.
■Assemblyprocedure
1)FittheO-ringintotheorificesection.
2)Insertthecartridgefittingintotheproductbody.
3)Pleaseinsertthepinallthewayfromthefrontoftheproduct.
Note)Afterdisassembly/cleaning,pleasere-setthresholdvalue.
Push-infitting fortubing
Orifice
O-ring
MAINTENANCE
