(1)Toinstallthebracket(modelnumber:GPS3-B),pleaseusetheincludedmountingscrewsandinstallfrom
thebackoftheproduct.
Mountingscrewtighteningtorqueshouldbe1.2±0.12N·m.
(2)Aftermountingbracket(modelnumber:GPS3-B),pleaseattachittothewall.
InstallwithM5equivalentscrews(2).
２．３ Piping
a）Flushtheairpipingtobeusedsufficientlybeforeconnectingtheregulator.
Ifdustorsealantenterstheproductduringpipingwork,thismay
causetheproducttomalfunctionoroperateincorrectly.
b）Ifdustorsealantenterstheproductduringpipingwork,thismay
causetheproducttodeclineinperformance.
c）Whenconnectingthepiping,tightenwithpropertighteningtorque.
d）Userust-resistantmaterialsuchasnylontubesorstainlesssteelpipesforpiping
material.
e)Whenusingsteelpipes,securelyfixthepipetopreventexcessivebendingforce
frombeingappliedtotheconnection.
Mountingscrew
CAUTION
INSTALLATION
２
[SM-P00143-A] −6−
