(1)Flushairintothepipetoblowoutforeign
substancesandchipsbeforepiping.
(2)Whenusingsealmaterial,takecaretoavoidgettingitinthepipesoroverflowingontheexteriorsurface
ofthepipes.
Whenapplyingfluororesinsealingtapetothescrewthreads,windthetapetwoorthreetimesaround
thethreadsbutleavetheoneortwothreadsatthepipeenduncovered.
Firmlypressthetapeagainstthethreadsusingthetipofyourfingernail.
Whenapplyingliquidtypesealmaterial,applythematerialtoallthethreadsexceptoneortwothreads
atthepipeendandtakecarenottoapplytoomuchofit.
Neverapplythesealmaterialtothefemalethreadsinthedevicesidepipingport.
(3)Useappropriatetorquetotightenthepipeswhenconnectingthem.
Thepurposeistopreventairleakageanddamagetobolts.
Firsttightentheboltsbyhandtoensurethatthethreadsarenotdamaged,thenuseatool.
２．４ Wiring
a)Usewithpowersupplyvoltageandoutputinthespecifiedrange.
Applyingavoltagethatisoutsideofthespecifiedrangemaycausemalfunction,
damagetothesensor,electricalshock,and/orfire.
Donotuseanyloadthatexceedstheratedoutput.
Usingsuchaloadmayresultindamagetotheoutputpartorfire.
b）Whencarryingoutelectricaconnections,pleaseperformdisassemblingand
assemblingworkafterreadingtheInstructionManualcarefullyandwithfull
understandingofitscontents.
Portthread
Rc1/8 3to5
TighteningtorqueN·m
DANGER
INSTALLATION
２
