299 211.0 - RHB klappbares SW 4,50 m - 5,40 m LEXION 1.1.3
Key to symbols
Key to symbols
This CLAAS REPAIR MANUAL uses some symbols
as defined in the “DIN 30600 Symbol summary” by
the German Standardisation Institute.
The meaning of these symbols will be easily
recognised and remembered by the user.
These symbols are to help to quickly recognise
recurring service procedures and they also help to
communicate information shown on the illustrations.
Dismantle,
remove
Grease
Prevent damage
to materials
Disassemble Oil Use special tool
Assemble Adjust / set
Drain,
outlet
Install,
mount on
Check visually
Fill,
filler opening
Mark
Unlock, release,
secure
Overflow
Balance
Lock by
means of liquids,
glue, seal
Bleed
Possibly
reusable
Underprop,
support
Renew on
each assembly
Observe direction
of installation
Key to symbols
