299 211.0 - RHB klappbares SW 4,50 m - 5,40 m LEXION 1.6.1
Drive diagram
DRIVE DIAGRAM
General information on drives
The figures 1 and 2 show an overview of drive belts
and chains.
CAUTION!
When the belts are removed and during
extended standstill periods of the machine,
protect the grooves and/or the contact faces of
the drive belts on the pulleys against corrosion.
Before re-installing the belts, clean the groove
faces and/or the contact faces of the pulleys.
(Fig.1,2)
Drive diagram, left-hand
40 Feed drive chain
41 Drive chain
42 Reel drive belt
43 Drive chain
44 Knife drive belt
(Fig. 1)
1
Drive diagram
