1.4.2 RHB klappbares SW 4,50 m - 5,40 m LEXION - 299 211.0
Tightening torques
Hydraulic screw fittings
Tightening torques for hydraulic screw fittings with O-ring according to ISO 6149
Dimensions Tightening torque according to ISO 6149
M 8 x 1
7
+2
Nm
M 10 x 1
11
+4
Nm
M 12 x 1.5
16
+5
Nm
M 14 x 1.5
23
+8
Nm
M 16 x 1.5
29
+10
Nm
M 18 x 1.5
38
+13
Nm
M 20 x 1.5
46
+15
Nm
M 22 x 1.5
67
+22
Nm
M 24 x 1.5
86
+29
Nm
M 26 x 1.5
103
+34
Nm
M 27 x 2
103
+34
Nm
M 30 x 2
170
+57
Nm
M 33 x 2
200
+67
Nm
M 36 x 2
245
+82
Nm
M 38 x 2
245
+82
Nm
M 39 x 2
310
+103
Nm
M 42 x 2
380
+127
Nm
M 45 x 2
440
+147
Nm
