Claas TUCANO 2017 - Overview Walker; Walker Machine Components

Overview Walker
5
1.
Feeder
chains
2.
Stone
trap
3.
Accelerator
4.
Pre-concave
5.
Threshing
drum
6.
Main
concave
7.
Impeller
8.
Straw
walkers
9.
Intensive separation system
10.
Return pan
11.
Preparation floor
12.
Fan
13.
Upper sieve
14.
Lower sieve
15.
Grain auger
16.
Returns auger
17.
Chaff spreader
18.
Straw chopper
19.
Deflectors
20.
Returns elevator
21.
Grain elevator
22.
Grain tank
23.
Unloading Tube
