(Pl: Programme Identification)
Press the button 6 on which an RDS station has been stored, and if
this station is not received (the "RDS" indicator (@) is blinking), press
the same button again, “SEARCH" will be displayed and a station broadc
asting the same programme will be received.
* Regional Programme Function (REG)
REG ON (REG indicator fit):
Only local (regional!) radio broadcasts in the local area will be sought.
REG OFF (REG indicator off):
If you are receiving a regional station in a certain area and you enter
a different area, the regional station for that area will be received. In
the RDS mode, the REG function will turn on/off each time you press
the button @3 for more than 2 seconds.
%& RDS EON (Enhanced Other Networks Information)
When EON data is received for an RDS broadcast, the "EON" indicator
(e) will fight up.
1. If you are waiting to receive traffic information, and the "EON"
indicator lights up, traffic information will be broadcast when the traffic
information begins, even if it is on a different station to the one you
are currently receiving.
2. When the “EON” indicator is lit, if you press a button ©) , the
Station with the best signal in that area will be received instantly.
%& Certain countries and certain stations do not transmit EON dats.
%* TA (Traffic Announcement) Button 43)
When traffic information begins, this is given top listening priority.
When you press the button 3) , the "TA" indicator @) lights up, and
a traffic information station is sought If sucha station is found, the
"TP" indicator (©) lights up, and the traffic information wait state
becomes operative. When you press the button () again, this state is
released.
If you press the button (3 while listening to traffic information, the
traffic information broadcast is cancelled and the traffic information wait
State becomes operative again.
lf no traffic information station is found, "NO TRA" is displayed, so you
then press the button (3) to release the state. Traffic Information is
automatically reproduced at the preset volume.
1. When the traffic information begins, "TRA INFO" is displayed.
2. While you are listening to traffic information, loudness is turned OFF,
3. Even if the "TA" indicator @) is lit, when a station not broadcasting
traffic information is being received, a traffic information station will
be sought when you press the button @ .
m@ FEATURES:
TUNER
4. @ Preset Scan when "TA" Indicator @) is Lit:
When you press the button _ only stations broadcasting traffic
information will be covered by the Preset Scan.
@ Auto Store when "TA" indicator @) is Lit:
lf you press the button for more than 2 seconds, only stations
broadcasting traffic information will be auto stored.
%€ Traffic information and Emergency Broadcast Volume Setting
Method
1. Press the button 43) for more than 2 seconds.
2. Adjust the volume using the buttons @ and @
3. if you press any button other than G) . @ or © . and take
no other action for 5 seconds, the previous state will become
operative again.
4. Listening to Cassette Tapes
Cassette Tape Playback
Insert the cassette tape horizontally so that the side where the tape
can be seen is on the right.
*K Eject Button @& ©
When you press button ©) , the cassette tape is ejected.
% Fast Forward and Rewind/Programme Selector Buttons @ mC)
e Using Fast Forward/Rewind
1. During top side playback (playback direction is toward the right):
Fast forward: Press button (9) until it focks
Rewind: Press button until it locks
2. During bottom side playback (playback direction is toward the
left):
Fast forward: Press button until it locks
Rewind: Press button (8) until it locks.
3. Release
Press the opposite button-either or @)
@ Changing the Programme (Running Direction)
When you press buttons and (9) simultaneously the tape
playback direction will change.
M@ RDS (Radio Data System): Pl(Programme Identification), AF (Alternative Frequency), TP { Traffic Programme Identification), TA (Traffic Announcement),
PS(Programme Service Name), REG(Regional Selection), EON(Enhanced Qther Networks). Mf Electronic Quartz-Locked PLL Tuning Ml One-Touch Memory
(12 FM, 6 MW/LW) i Tuning Modes: Manual Tuning and Station Seek in both directions Hl Preset Scan (PS) & Auto Store (AS) on FM/MW/LW ff DX/Local
Switch M Super SASC Ii(Signal Actuated Stereo Control) & CZ1 Noise Cancellor M@ Adjustable TA Level
TAPE SECTION
M@ Electronic Servo Motor Ml Hard Permailoy Head & Illuminated Tape Door
AUDIO SECTION
Mi Loudness, Fader, Bass / Trable Controls M Maximum Power Output: 4x7 W
GENERAL
Mi Power Antenna Activator MB Multi-Mode LCD Display @ Fully Detachable Contro! Panel Ml DIN Chassis
m= COMPONENT VIEW:
MAIN UNIT
92 1—9257—00
PART’S BAG
s)
HOOK PLATE SPACER SPECIAL. SC
330—8216—01 345—3653—-01 716—-0726—-O1
ARB4171R CR705R
