Clarion CZ301E User Manual

27
English
MIC
7) Wiring and Connections
Refer to next page.
A
B
C
2
4
6
8
1
3
5
7
1
3
5
7
2
4
6
8
Rear Right / SUB OUT 2
Rear Left / SUB OUT 1
SWC
Refer to next page
Rear audio output (Left)/
White
Red
2 Channel Amplier
Antenna
Black
Black
Black
Black
Black
Black
(Black)
Rear audio output (Right)/
Steering wheel
control terminal
External
microphone
Subwoofer output 1
Subwoofer output 2
Fuse 15A
(RCB-199:Sold by separately)
Downloaded from Caradio-Manual.com Manuals

Clarion CZ301E Specifications

General

Audio system	MOS-FET
MP3 playback	Yes
Audio formats supported	MP3, WMA
Supported radio bands	AM, FM
Product color	Black
Audio output channels	4.0 channels
Maximum power per channel	45 W
Illumination color	Blue
I/O ports	1x Aux 1x USB
