Clarion CZ301E User Manual

28
English
• Connecting to the external amplier
External ampliers can be connected to the 2 channel RCA output connections.
Ensure that the connectors are not grounded or shorted to prevent damage to the
unit.
8) Connecting the accessories
A
B
C
16
14
12
10
8
6
4
2
15
13
11
9
7
5
3
1
1
3
5
7
2
4
6
8
1
3
5
7
2
4
6
8
Battery +
Phone Mute
Front left +
Rear left +
ACC +
AMP Remote
Ground
ear right (+) / Purple
Rear right (-) / Purple with black stripe
Rear left (+) / Green
Rear left (-) / Green with black stripe
Front right (+) / Grey
Front right (-) / Grey with black stripe
Front left (+) / White
Front left (-) / White with black stripe
Battery 12V(+) / Yellow
Remote On / Blue with white stripe
ACC+ / Red
Ground / Black
Illumination / Orange with white stripe
Illumination
Rear right -
Front right -
Rear left -
Front left -
Front right +
Rear right +
YellowYellow
RedRed
For VW and Audi: Change wiring like above.
R
Downloaded from Caradio-Manual.com Manuals

Clarion CZ301E Specifications

General

Audio system	MOS-FET
MP3 playback	Yes
Audio formats supported	MP3, WMA
Supported radio bands	AM, FM
Product color	Black
Audio output channels	4.0 channels
Maximum power per channel	45 W
Illumination color	Blue
I/O ports	1x Aux 1x USB
