Clarion CZ702 Owners And Installation Manual

7) Wiring and Connections
Refer to next page Refer to next page
HD RADI HD RADIO O
MIC MIC
S
W
SW
C C
4 Channel Amplier 4 Channel Amplier
2 Channel Amplier 2 Channel Amplier
Black Black
Black Black
Black Black
Black Black
S
teering wheel
control terminal
Steering wheel
control terminal
USB Connector USB Connector
External
microphone External microphone
(RCB-199:Sold by separately) (RCB-199:Sold by separately)
White White
Gray Gray
Red Red
Left Left
Right Right
Front audio
output terminal
Mid audio
output terminal
White White
Black Black
Red Red
Left Left
Right Right
Rear audio
output terminal
High audio
output terminal
Purple
Purple
Rear audio output(Left)
Rear audio output(Right)
Purple
Purple
Subwoofer output 1
Monaural output
Subwoofer output 2
Monaural output
(Black) (Black)
SiriusXM SiriusXM
THD301
(sold separately)
THD301
(sold separately)
SiriusXM Connect™
Vehicle Tuner to be
connected
(sold separately)
SiriusXM Connect™
Vehicle Tuner to be
connected
(sold separately)
HD BUS HD BUS
Antenna Antenna
(Black) (Black)
(Black) (Black)
• Normal mode • 2 Way mode
SUB OUT 1 REAR OUT L SUB OUT 1 REAR OUT L
SUB OUT 2 REAR OUT R SUB OUT 2 REAR OUT R
REAR OUT HIGH OUT REAR OUT HIGH OUT
FRONT OUT MID OUT FRONT OUT MID OUT
USB iPod/iPhone USB iPod/iPhone

Clarion CZ702 Specifications

General

MP3 playback	Yes
Audio formats supported	MP3, WMA
USB version	2.0
Line outputs (RCA)	6
USB ports quantity	1
DIN size	-
Output power	76 W
Product color	Black
Volume control	Rotary
Frequency range	20 - 20000 Hz
Disc types supported	CD
Audio output channels	4.0 channels
Maximum power per channel	19 W
Signal-to-Noise Ratio (SNR)	94 dB
FM band range	87.9 - 107.9 MHz
Supported radio bands	AM, FM
Display type	LCD
Key illumination color	Blue

Weight and Dimensions

Weight	1300 g
Dimensions (WxDxH)	188 x 190 x 58 mm
