Clarion CZ702E

English
18
CZ702E
7) Wiring and Connections
Refer to next page
MIC
SWC
4 Channel Amplier
2 Channel Amplier
Black
Black
Black
Black
Steering wheel
control terminal
USB Connector
External
microphone
(RCB-199:Sold by separately)
White
Gray
Red
Left
Right
Front audio
output terminal
White
Black
Red
Left
Right
Rear audio
output terminal
Purple
Purple
Subwoofer output 1
Monaural output
Subwoofer output 2
Monaural output
Antenna
(Black)
DAB
DAB302E (sold separately)
(Black)
Refer to next page
MIC
SWC
4 Channel Amplier
2 Channel Amplier
Black
Black
Black
Black
Steering wheel
control terminal
USB Connector
External
microphone
(RCB-199:Sold by separately)
White
Gray
Red
Left
Right
Mid audio
output terminal
White
Black
Red
Left
Right
High audio
output terminal
Purple
Purple
• Normal mode • 2 Way mode
Antenna
(Black)
DAB
DAB302E (sold separately)
(Black)
SUB OUT 1 REAR OUT L
SUB OUT 2 REAR OUT R
REAR OUT HIGH OUT
FRONT OUT MID OUT
SUB OUT 1 REAR OUT L
SUB OUT 2 REAR OUT R
REAR OUT HIGH OUT
FRONT OUT MID OUT
Rear audio output(Left)
Rear audio output(Right)
USB iPod/iPhone
USB iPod/iPhone
