Clarion DXZ946MP User Manual

2 DXZ946MP
English
Thank you for purchasing this Clarion product.
∗ Please read this owner’s manual in its entirety before operating this unit.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ This manual includes the operating procedures of the CD changer and TV tuner connected via the
CeNET cable. The CD changer and TV tuner have their own manuals, but no explanations for
operating them are described.
1. FEATURES
• Optiomedia Display:
16-Gradation 320 x 64 Full-dot LCD with Touch Panel Control
• AC PROCESSOR III:
Time Alignment/”VIRTUAL SPACE ENHANCER”/”Dolby Pro Logic II”/3 BAND P.EQ
• ADF (Anti Distortion Filter)
• Codematic
• 24-Bit Digital to Analog Converter for Audiophile
• 4V / 6ch Gold Plated RCA Output and 2ch RCA AUX Input with 3 Level Adjustments
• 5.1ch Surround Decoder Control
Contents
1. FEATURES...................................................................................................................................... 2
2. PRECAUTIONS .............................................................................................................................. 3
Sloping Console .............................................................................................................................. 4
Handling Compact Discs ................................................................................................................. 4
3. CONTROLS .................................................................................................................................... 5
4. NOMENCLATURE .......................................................................................................................... 6
Names of the Buttons and their Functions ...................................................................................... 6
Major Button Operations when External Equipment is Connected to this Unit ................................ 7
Display Items ................................................................................................................................... 8
Display Operations .......................................................................................................................... 8
5. DCP ................................................................................................................................................. 9
6. REMOTE CONTROL .................................................................................................................... 10
Inserting the Batteries .................................................................................................................... 10
Functions of Remote Control Unit Buttons ..................................................................................... 11
7. OPERATIONS ............................................................................................................................... 12
Basic Operations ........................................................................................................................... 12
AC-Processor III Operations .......................................................................................................... 17
Radio Operations ........................................................................................................................... 23
CD / MP3 / WMA Operations ......................................................................................................... 26
Different Pieces of Music Heard by Plural Listeners (2-ZONE function) ....................................... 31
Operations Common to Each Mode .............................................................................................. 32
8. OPERATIONS OF ACCESSORIES .............................................................................................. 45
CD Changer Operations ................................................................................................................ 45
TV Operations ............................................................................................................................... 48
5.1ch Surround Decoder Operations ............................................................................................. 51
9. IN CASE OF DIFFICULTY ............................................................................................................ 56
10. ERROR DISPLAYS ....................................................................................................................... 58
11. SPECIFICATIONS ......................................................................................................................... 59

Clarion DXZ946MP Specifications

FM Tuner

frequency range	87.0 MHz to 108.0 MHz
usable sensitivity	9 dBf
50dB quieting sensitivity	15 dBf
alternate channel selectivity	70 dB
stereo separation (1 kHz)	35 dB
frequency response (±3 dB)	30 Hz to 15 kHz

AM Tuner

frequency range	531 kHz to 1629 kHz
usable sensitivity	25 µV

CD Player

system	Compact disc digital audio system
usable discs	Compact disc
frequency response (±1 dB)	5 Hz to 20 kHz
signal to noise ratio (1 kHz)	100 dB
dynamic range (1 kHz)	96 dB
harmonic distortion	0.01%

Audio

maximum power output	212 W (53 W × 4 ch)
continuous average power output	18 W × 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
bass control action (50 Hz)	±12 dB
treble control action (12.5 kHz)	±12 dB
line output level (CD 1 kHz)	4 V/F 2ch + 4V/R 2ch

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable)
current consumption	Less than 15 A, 3A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)
weight / source unit	1.7 kg (3.74 lb.)
weight / remote control unit	80 g (2.82 oz.)
dimensions / source unit	178 (Width) × 50 (Height) × 155 (Depth) mm
dimensions / remote control unit	44 (Width) × 110 (Height) × 27 (Depth) mm
