4. NOMENCLATURE
Names of the Buttons and their Functions
[RELEASE] button
• Remove the DCP.
Photo Sensor
• This sensor detects the brightness inside your
car. When the auto-dimmer function is set to
“AUTO”, the brightness of the display is
dimmed according to the brightness detected
by this sensor.
[ROTARY] knob
• Press the knob to turn the power ON. Each
press of this knob switches the mode.
• Press and hold the knob for 1 second or longer
to turn the power OFF.
• This knob can also be turned to adjust the
volume, or to adjust the various settings in the
adjust mode.
[Q] button
• Opens/closes the control panel.
If a disc is already loaded, it will be ejected
when the control panel is opened.
Note:
If the disc is not ejected, hold down the [ Q ] button
for 1 second or longer.
[A] button
• Use this button to set or adjust the various
settings in the adjust mode.
• Use this button to enter station names in the
radio mode or disc titles in the CD mode.
[SOUND] button
• Use this button for setting or adjusting various
settings such as audio space.
• Holding this button down for 1 second or
longer also toggles the 2-ZONE function ON
and OFF.
[I] button
• Immediately calls up a favorite radio station
regardless of the current mode. (This is the
ISR function.) You can store radio stations to
the [I] button by holding this button down for 2
seconds or longer in the radio mode (when the
2-ZONE function is “OFF”).
Switches the operation of the 2-ZONE function.
Holding this button down for 1 second or
longer switches the 2-ZONE type (when the 2-
ZONE function is “ON”).
[ ] button
• Pauses and unpauses a track (in the CD
mode).
Display
• Displays the various information that indicates
the operating state of this unit such as tuning/
play state and indicators.
•Touch the display with your finger, and touch
to enable operation. (cf. page 8)

Clarion DXZ946MP Specifications

FM Tuner

frequency range	87.0 MHz to 108.0 MHz
usable sensitivity	9 dBf
50dB quieting sensitivity	15 dBf
alternate channel selectivity	70 dB
stereo separation (1 kHz)	35 dB
frequency response (±3 dB)	30 Hz to 15 kHz

AM Tuner

frequency range	531 kHz to 1629 kHz
usable sensitivity	25 µV

CD Player

system	Compact disc digital audio system
usable discs	Compact disc
frequency response (±1 dB)	5 Hz to 20 kHz
signal to noise ratio (1 kHz)	100 dB
dynamic range (1 kHz)	96 dB
harmonic distortion	0.01%

Audio

maximum power output	212 W (53 W × 4 ch)
continuous average power output	18 W × 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
bass control action (50 Hz)	±12 dB
treble control action (12.5 kHz)	±12 dB
line output level (CD 1 kHz)	4 V/F 2ch + 4V/R 2ch

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable)
current consumption	Less than 15 A, 3A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)
weight / source unit	1.7 kg (3.74 lb.)
weight / remote control unit	80 g (2.82 oz.)
dimensions / source unit	178 (Width) × 50 (Height) × 155 (Depth) mm
dimensions / remote control unit	44 (Width) × 110 (Height) × 27 (Depth) mm
