20 M109
English
FM Tuner
Frequency Range:
U.S.A: 87.9 MHz to 107.9 MHz
Europe: 87.5 MHz to 108.0 MHz
Australia: 87.0 MHz to 108.0 MHz
Usable Sensitivity: 9 dBf
50dB Quieting Sensitivity: 15 dBf
Alternate Channel Selectivity: 70 dB
Stereo Separation (1 kHz): 35 dB
Frequency Response (±3 dB): 30 Hz to 15 kHz
AM Tuner
Frequency Range:
U.S.A: 530 kHz to 1710 kHz
Europe: 531 kHz to 1602 kHz
Australia: 531 kHz to 1629 kHz
Usable Sensitivity: 25 μV
CD Player
System: Compact disc digital audio system
Usable Discs: Compact disc
Frequency Response (±1 dB): 5 Hz to 20 kHz
Dynamic Range (1 kHz): 85 dB
Harmonic Distortion: 0.01%
Audio
Maximum Power Output: 200 W (50 W ✕ 4 ch)
Bass Control Action (100 Hz): +14 dB, –14 dB
Treble Control Action (10 kHz): +14 dB, –14 dB
Line Output Level (CD 1 kHz): 1.8 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable), negative
ground
Current Consumption: Less than 15 A
Speaker Impedance: 4 Ω (4 Ω to 8 Ω allowable)
Weight / Source unit: 2.53 lb. (1.15 kg)
Dimensions / Source unit:
7" (Width) ✕ 2" (Height) ✕ 6-1/8" (Depth)
[178 (W) ✕ 50 (H) ✕ 155 (D) mm]
Note:
• Specifications and design are subject to change
without notice for further improvement.
9. SPECIFICATIONS
Power Output :
20 W RMS x 4 Channels at 4
and 1 % THD+N
Signal to Noise Ratio:
88 dBA (reference: 1 W into 4 )
01_M109_EN.book Page 20 Thursday, February 19, 2009 10:43 AM
